| Contact Rating | DC 5V 10mA |
| Contact Resistance | 100mΩ max |
| Insulation Resistance | 100MΩ min. 100V DC |
| Operating Force | 100gf,200gf |
| Travel | 4-direction-25°-0°+25° Center push0.9mm±0.1mm |
| Operating Life | 100,000 cycles |
| Operating Temp | -25°C ~ +85°C |
| Storage Temp | -25°C ~ +85°C |
