| Contact Rating | DC12V 20mA |
| Contact Resistance | 100mΩ max |
| Insulation Resistance | 100MΩ min. 500V DC |
| Operating Force | 140,220gf |
| Travel | 4-direction4°±2° Center push0.2mm±0.1mm |
| Operating Life | 50,000 cycles |
| Operating Temp | -25°C ~ +85°C |
| Storage Temp | -25°C ~ +85°C |
